TDA2822M STMicroelectronics DUAL LOW-VOLTAGE POWER AMPLIFIER

SUPPLY VOLTAGE DOWN TO 1.8V

. LOW CROSSOVER DISTORSION
. LOW QUIESCENT CURRENT
. BRIDGE OR STEREO CONFIGURATION

DESCRIPTION

The TDA2822M is a monolithic integrated circuit in8 lead Minidip package. It is intended for use as dual audio power amplifier in portable cassette players and radios.




Datasheet
