UTC78D05AL 0.5A positive voltage regulator

3-TERMINAL 0.5A POSITIVE VOLTAGE REGULATOR

DESCRIPTION

The UTC 78DXX family is monolithic fixed voltage regulator integrated circuit. They are suitable for applications that required supply current up to 0.5A.

FEATURE

*Output current up to 0.5 A
*Fixed output voltage of 3.3V,4.7V,5V, 6V, 8V, 9V,
12V, 15V ,18V and 24V available
*Thermal overload shutdown protection
*Short circuit current limiting
*Output transistor SOA protection

Datasheet
